Supressing features helps in the cases we want to temporarily undo, or try a different design for an element in the part.Hiding sketches helps to keep our edit workspace clean and free of clutter.Use it and points to create planes for other sketches to be parallel or perpendicular to curved surfaces Project geometry in sketch mode is our friend.Dimensions of lines and shapes in sketches can be set by referencing other dimensions in the same sketch.First sketch for every part should start at the origin, and the orientation for every part should be standardised in a product.In addition, I have picked up some of my own as well. Throughout the whole module, the professor has taught us some neat tips and tricks to make our lives easier when we are modelling the products.
So, we will need to figure out and choose one style or way of working which we prefer. There are multiple ways to do things which will give us the same result. We have to plan ahead and think about which element or side we would want to start making our part from. Throughout the whole process, the most important part is arguably the planning part. There goes another 10 hours of my life, redoing the same assignment.
My professor did not take my mistake of installing and using the wrong version too kindly, and told me to redo the whole assignment in the 2020 version. I was not present for the first lesson as I had add/dropped into this mod, and did not know till the first assignment submission. In addition, if your professor is as particular as me, they will purposely request that you have the 2020 version installed, even if they can open the latest 2021 files. Thus, it is best to follow the school version in the event you have to use to school computers to open and edit your files for whatever reason. Since Inventor is not backwards compatible, which means Inventor 2020 will not be able to open any files created using Inventor 2021. From what I remember, it is Inventor 2020. But wait!! Not so fast! Even before you start downloading and installing Inventor, please check and confirm with your professors the version the school is using. After your educational access has been approved, you would think it’s time to download and install the latest version of Inventor.
